The Honda Clarity Fuel Cell is not a conventional engine but a hydrogen fuel cell powertrain produced between 2016 and 2021. It generates electricity through an electrochemical reaction between hydrogen and oxygen, powering an electric motor with only water vapor as exhaust. The system features a 103 kW (139 PS) electric motor and a 141 kW fuel cell stack, delivering 300 Nm of instant torque for smooth, quiet propulsion.
Fitted exclusively to the Clarity Fuel Cell sedan, t…
All production years 2016–2021 meet California Air Resources Board (CARB) Zero Emission Vehicle (ZEV) standards (CARB Executive Order #G-15-008).
The Honda Clarity Fuel Cell powertrain is a hydrogen-electric system engineered for zero-emission sedans (2016-2021). It combines a high-output fuel cell stack with a lithium-ion battery to deliver smooth, linear acceleration and a driving range of up to 589 km (366 miles). Designed to meet CARB ZEV standards, it prioritizes environmental performance and technological innovation.
| Parameter | Value | Source |
|---|---|---|
Power source | Hydrogen Fuel Cell | |
Fuel type | Hydrogen (H₂) | |
Electric motor output | 103 kW (139 PS) | |
Fuel cell stack output | 141 kW | |
Torque | 300 Nm | |
Battery capacity | 1.7 kWh Lithium-ion | |
Driving range | 589 km (366 miles) EPA | |
Refueling time | 3–5 minutes (to 100%) | |
Emissions | Zero tailpipe emissions (H₂O only) | |
Cooling system | Dedicated fuel cell and powertrain cooling circuits | |
Hydrogen storage | Three 70 MPa (10,000 psi) tanks (141 L total) | |
System weight | Approx. 220 kg (fuel cell stack and motor) |
The Honda Clarity Fuel Cell powertrain was used exclusively in the Honda Clarity Fuel Cell sedan with front-wheel-drive, transverse mounting. This system received no platform-specific adaptations, as it was designed solely for this model. All specifications are documented in OEM technical bulletins.
Engine Finders UK Ltd, which operates EngineCode.uk, can pass your enquiry to engine suppliers in the UK. The service is for vehicles in the United Kingdom, with UK delivery or fitting. This is a commercially connected service, and sending an enquiry does not confirm diagnosis or compatibility.
Diagnostic reminder: If a technician has recommended replacing the engine, you can send an enquiry to engine suppliers in the UK. Confirm the diagnosis first: an engine-code record does not diagnose a fault.
The Clarity Fuel Cell's primary reliability focus is long-term fuel cell stack performance and hydrogen system integrity, with elevated incidence in extreme climate use. Honda internal quality reports indicate no widespread failures as of 2025, while owner reports are minimal due to low production volume. Adherence to specialized service schedules and use of certified hydrogen fueling stations are critical for system longevity.
Analysis derived from Honda technical bulletins (2016-2021) and aggregated owner-reported data (2017-2023). Repair procedures should follow manufacturer guidelines.
The most common questions about engine codes, what they mean, how to find them and how this database works
As a low-volume, technologically advanced vehicle, long-term reliability data is limited. Honda designed the fuel cell stack for a 10-year/150,000-mile lifespan. Key considerations are the specialized maintenance requirements and the availability of hydrogen fueling infrastructure. With proper care and servicing by certified technicians, the system is expected to be very reliable.
Reported issues are infrequent but include fuel cell stack output degradation over very high mileage, hydrogen sensor faults, coolant pump failures for the fuel cell circuit, and air compressor noise or failure. These are complex systems, and repairs are typically handled under warranty or by specialized Honda technicians.
The Clarity Fuel Cell powertrain was used exclusively in the Honda Clarity Fuel Cell sedan (2016-2021). It was not available in any other Honda model. This powertrain was created specifically for this limited-production, zero-emission vehicle.
No. The power output is strictly controlled by the fuel cell stack and electric motor calibration for efficiency, safety, and durability. There are no aftermarket tuning options or ECU remaps available for this system. Modifying the system would likely void warranties and compromise safety.
The EPA-rated driving range is 589 km (366 miles) on a full tank of hydrogen. Real-world range can vary based on driving style, climate conditions, and terrain. Refueling takes approximately 3-5 minutes at a certified hydrogen station, offering a refueling experience similar to a conventional petrol car.
This question is not applicable. The Clarity Fuel Cell does not have an internal combustion engine. It uses a hydrogen fuel cell to generate electricity, which powers an electric motor. There are no pistons, valves, or timing chains that can interfere with each other.
The Clarity Fuel Cell does not require engine oil as it has no internal combustion engine. However, it does require specific coolants for the fuel cell stack and powertrain, and transmission fluid for the reduction gearbox. These fluids have their own replacement intervals specified in the owner's manual and must be serviced by qualified technicians.
